2025 HARLEY-DAVIDSON® PARTS CATALOG: POLICE MODELS

READER'S COMMENTS

The Harley-Davidson Service Communications Department maintains a continuous effort to improve the quality and usefulness of its publications. To do this effectively, we need user feedback - your critical evaluation of this manual.

Please comment on the completeness, accuracy, organization, usability, and readability of this manual.

Please list the page, item, and part number(s) of any errors you find in this manual.

Please tell us how we can improve this manual.

Name		Document 94001266
Occupation		Dealership
Street		Department
City	State	Zip

2025 HARLEY-DAVIDSON® PARTS CATALOG: POLICE MODELS - Publication Template Name

Return this form to:
Harley-Davidson Motor Company
Department 625 Service Communications
P.O. Box 653
Milwaukee WI 53201 USA

PLEASE ADD ANY OTHER COMMENTS HERE

GENERAL INFORMATION

THIS IS NOT AN ASSEMBLY MANUAL AND SHOULD NOT BE USED AS SUCH.

About this Manual

This Parts Catalog has been prepared to make it easier for you to order parts for your motorcycles. The numbers shown in the illustrations correspond to the numbers in the "INDEX NO." column in the parts lists. Consult the illustrations when ordering parts to make sure that you receive all the required parts. The number in parentheses following the part description is the quantity needed for complete assembly. If there is no number in parentheses, only one is used. Prices of parts in this catalog are published separately.

When ordering parts, the following instructions should be followed carefully.

Make sure to specify the correct part number for each item. The part numbers appear under the "PART NO." column in the parts lists.
Orders may be placed via your computer for all parts. Review your system documentation on placing orders electronically. All non-warranty replacement crankcase orders require return of the complete left crankcase half with vehicle identification number (VIN). All non-warranty replacement frame orders require return of the steering neck with vehicle identification number (VIN). Non-compliance will result in a fine. See non-warranty frame and crankcase policy or contact Dealer Services.
The sale or use of these parts or accessories does not grant the purchaser a license or other right under any Harley-Davidson patent.
All parts that were added for the new model year will have the entire line shaded on the parts list page. This can be used to identify any new parts that are unique to a specific model, and help distinguish new and previous model year parts.
Parts marked "RESTRICTED SALE PART" are limited edition items and can only be ordered as direct replacements.
Orientation symbols are used when the illustration is not in the standard "Right-Front" orientation. The symbol is a motorcycle with an arrow in the front indicating the direction of view. The symbol is at the bottom left or right side of the illustration page.
To request a missing or loose part, simply submit a Return Material Authorization (RMA) claim on h-dnet.com with code "T-part not included with vehicle" for all vehicle missing parts claims. Then place an order for the missing item on your next Parts and Accessories order. Upon filing the RMA claim, your dealership will be credited for the dealer net cost of the part. The Vehicle Identification Number must be included on the RMA claim in order for you to receive credit. This process is to be used for vehicles manufactured at all plants.

To the best knowledge of Harley-Davidson Motor Company, the material contained herein is accurate as of the date this publication was approved for printing. Harley-Davidson Motor Company reserves the right to change specifications, equipment or designs at any time without notice and without incurring obligation.

GENERAL INFORMATION

LOOSE PARTS

The Loose Parts section is located at the back of this parts catalog. This section lists the parts which are shipped unfastened with the vehicles covered in this catalog.

HARDWARE LIST

The Hardware List is located at the back of this parts catalog. This section contains the information for each piece of hardware found in each parts list.

NEW PARTS LIST

The New Parts List is located at the back of this parts catalog. This list serves as a summary of new parts.

NUMERICAL INDEX

The Numerical Index is located at the back of this parts catalog. This index includes all part numbers used in this catalog and the page numbers of where they can be found.

COMPONENT TYPES AND INTRODUCTION DATES

The Component Types and Introduction Dates section is located at the back of this parts catalog. This section contains a list of component part numbers and year of introduction.

COMMON SERVICE PARTS

The Common Service Parts section is located at the back of this parts catalog. This section contains the most commonly ordered parts for service on vehicles covered in this catalog. These parts are ordered through the normal ordering process.

SIP (SERVICE INFORMATION PORTAL)

For the latest updates to these manuals, see the Service Information Portal.

VEHICLE IDENTIFICATION NUMBER

See Figure 4. A unique 17-digit serial, or vehicle identification number (VIN), is assigned to each motorcycle. For a description of each digit in the vehicle identification number (VIN), refer to Table 2.

The full 17-digit serial, or vehicle identification number (VIN), is stamped on the right side of the frame backbone at the rear of the steering head. The vehicle identification number (VIN) is also printed on a label on the right front downtube. An abbreviated vehicle identification number (VIN) is stamped on the left side crankcase between the front and rear cylinders.

POSITION	DESCRIPTION	POSSIBLE VALUES
1	World manufacturer identifier	1HD=Originally manufactured in the United States 5HD=Originally manufactured in the United States or Thailand for sale outside of the United States 932=Originally manufactured in Brazil MLY=Originally manufactured in Thailand
2	Motorcycle type	1=Heavyweight motorcycle (901 cm³ or larger)
3	Model	See VIN model table
4	Engine type	P=Milwaukee-Eight^™ 114 Engine, 1868 cm³
5	Calibration/configuration, introduction	Normal Introduction 1=Domestic (DOM) 2=California (CAL) 3=Canada (CAN) 4=ENG/EN2/HDI/HD4 5=Japan (JPN/JPN2) 6=Australia (AUS/AU2) 7=Brazil (BRZ) 0=ASEAN (AZN) A=China (CHN)
6	VIN check digit	Can be 0-9 or X
7	Model year	S=2025
8	Assembly plant	B=York, PA U.S.A. D=H-D Brazil-Manaus, Brazil (CKD) S=Tasit, Pluagdang, Rayong, Thailand
9	Sequential number	Varies

CODE	MODEL	CODE	MODEL
AJ	FLTRXP Police Road Glide^®	FH	FLHP Police Road King^®
FM	FLHTP Police Electra Glide^®

Index No.	Part No.	Description	Model(s)
1	16200660	ENGINE ASSEMBLY, complete (Air-Cooled) (Milwaukee-Eight® 114 engine) (chrome)	ALL
2	16200582	ENGINE ASSEMBLY, shortblock, with 91800064, crankcase, flywheel assembly, camshaft support plate assembly, balancer and cylinder studs (See Note)	ALL
3	91800064	KIT, shortblock installation, with upper end gasket kit, inner primary gasket kit, camshaft sprocket, camshaft drive chain and camshaft tensioner	ALL
Note: Cylinders, cylinder heads, camshaft, rocker arms, pushrods, pushrod covers, piston assemblies, tappets, oil pump, oil filter adapter, oil filter and cosmetic covers are not included with the shortblock assembly. These parts must be removed from the original engine and installed on the replacement shortblock assembly.

Part No.	Description
1009M	SCREW M6 X 1.0 X 20 socket head
10100062	LOCKNUT 7/16-20 flange (Grade F) (zinc)
10200032	SCREW 1/4-20 X 1/2 TORX, button hd with lockpatch, (Grade 8) (bright zinc)
10200042	SCREW No. 10-24 X 1-5/8 hex flange head full thread (Grade 5) (zinc)
10200059	SCREW 1/4-20 X 1-11/16 TORX socket button head matpoint (Grade 5) (black)
10200060	SCREW 1/4-20 X 2-5/8 TORX socket button head matpoint (Grade 5) (black)
10200062	SCREW No. 8-32 X 3/8 TORX pan head (zinc)
10200063	SCREW No. 8 X 1/2 TORX SEMS pan head (stainless)
10200064	SCREW No. 8-32 X 1 TORX pan head (zinc)
10200065	SCREW No. 8-32 X 5/8 TORX SEMS pan head, with lockpatch (stainless)
10200103	SCREW No. 8-32 X 1/2 TORX SEMS pan head, with lockpatch (stainless)
10200112	SCREW 1/4-20 X 2 TORX button head SEMS (Grade 5) (black)
10200120	SCREW 5/16 X 18 X 1.00 hex cap
10200134	SCREW 1/4-20 X 3/4 hex socket head (Grade 8) (zinc)
10200141	SCREW 1/4-20 X 1/2 hex socket button head (zinc)
10200142	SCREW 5/16-18 X 3/4 hex flange with internal hex SEMS, hardened (zinc)
10200147	SCREW No. 10-24 X 3/4 TORX socket button head SEMS (black)
10200155	SCREW No. 8-16 X 1 TORX pan head (zinc)
10200156	SCREW No. 8-32 X 3/8 phillips round head (stainless steel)
10200205	SCREW No. 10 X 1/2 pan head TORX, hardened (zinc)
10200217	SCREW 5/16-18 X 1-1/4 TORX SEMS, with lockpatch (zinc)
10200223	SCREW No. 10-24 UNRC X 3/4 TORX truss head (zinc)
10200258	SCREW 1/4-20 X 1-1/4 SEMS hex socket head (Grade 8) (zinc)
10200343	SCREW 5/16-18 X 3-1/4 flange (zinc)
10200350	SCREW 1/4-20 X 1-1/8 SEMS hex socket head (Grade 8) (zinc)
10200365	SCREW 1/4-20 X 1-1/16 TORX socket head SEMS (Grade 8) (zinc)
10200373	SCREW M6 X 1 X 18mm hex head (Grade 10.9) (zinc)
10200408A	SCREW 3/8-16 X 2 hex head, with washer (Grade 8) (zinc)
10200414	SCREW 5/16-18 X 5/8 button head SEMS TORX T-40, with lockpatch (Grade 8) (zinc)
10200422	SCREW 1/4-20 X 5/8 button head SEMS TORX T-27, with lockpatch (zinc)
10200429	SCREW 3/8-16 X 2-1/2 hex socket head with scotch grip (Grade 8) (zinc)
10200442	SCREW No. 8-32 X 5/16 tri-lobe thread forming (zinc)
10200446	SCREW 1/4-20 X 1 hex flange, with adhesive
10200463	SCREW 3/8-16 X 1-3/8 hex head with lockpatch (Grade 8) (zinc)
10200503	SCREW 5/16-18 X 1-1/4 12 pt. head (Grade 8)
10200546	SCREW No. 10-24 X 5/8 hex serrated flange, with scotch grip (zinc-nickel plate and seal)
10200569	SCREW 5/16-18 x 1/2 hex flange head, serrated
10200686	SCREW 10-24 X 1/2 button head with lockpatch, T-25 (Grade 5)
10201187	SCREW .375-16 X 2.750 TORX button head T-45
10201188	SCREW .312-18 X 1.30 TORX pan head T-40
10201381	SCREW 5/16-18 X 1.0 self tapping TORX T-40
10500015	SCREW 5/16-18 X 1-7/8 SEMS hex socket head
10500017	SCREW No. 10 X 3/8 pan head, TORX, plastite, hardened (zinc)
10500022	SCREW 5/16-18 X 1-1/2 SEMS hex socket head (Grade 8) (zinc)
10500036	SCREW 3/8-16 X 2 SEMS socket head (Grade 8.8) (black)
1062	SCREW 1/4-20 X 5/8 TORX head (Grade 8)
12600032	SCREW 1/2-13 X 2 hex head cap lock patch (Grade 5)
1332	SCREW No. 5/16 X 2-1/4 socket button head with lock patch (Grade 8)
1775	SCREW 1/4-20 X 4 hex socket head (Grade 8)
2361	SCREW No. 8-32 X 3/8 socket countersink head, with lockpatch
2445	SCREW 1/4-20 X 9/16 button head
2446	SCREW 1/4-20 X 5/8 TORX socket button head
2452	SCREW No. 12-24 X 13/16 pan head, with lockpatch
2478	SCREW No. 10-24 X 1/2 TORX button head
2479	SCREW 5/16-18 X 1-1/8 SEMS socket head
2482	SCREW 6-32 X 5/16 socket button head (stainless)
2531	SCREW No. 4-40 X 5/16 Pozidriv pan head (Grade 2)
2563	SCREW No. 10-24 X 5/8 TORX button head
2647B	SCREW No. 10-24 X 3/4 socket head, self-locking
2667	BOLT 5/16-18 X 2 hex head (Grade 5)
2692WB	SCREW No. 10-24 X 1/2 socket fillister head (Grade 8)
2708A	SCREW 5/16-18 X 1 socket head
2871W	BOLT 5/16-18 X 1-1/4 hex head (Grade 5)
2921A	SCREW 12-24 X 5/8 TORX pan head, T27
29269-83A	SCREW 15/16-18 X 5/8 hex button head, with lockpatch
2933	SCREW No. 10-24 X 1/2
2998	SCREW 5/16-18 X 1-1/8 hex head (Grade 5)
3022A	SCREW 1/4-20 X 5/8 socket fillister head, with lockpatch
3050	SCREW No. 10-24 X 1-3/8 TORX head
3057	SCREW 7/16-14 X 1-1/4 hex head with washer, with lock patch
3061	SCREW 1/4-20 X 5/8 SEMS hex head
3088	SCREW 1/4-20 X 1-1/2 socket button head (chrome)
3152	SCREW #10 X 1/2 TORX pan head
3210A	SCREW 5/16-18 X 1-1/4 knurled head
3225	BOLT No. 6 X 5/8 long phillips pan head (zinc)
3249	SCREW 5/16-18 X 1-3/16 socket head (Grade 8)
3275	SCREW 5/16-18 X 3/4 socket head (Grade 8)
3445	BOLT 5/16-18 X 9/16 hex head, with lockpatch (Grade 5)
3514	SCREW No. 8-32 X 1 fillister head (Grade 5)
35241-06	NUT 1-3/4-20 X .350 X 2-1/4 hex head
35244-06	SCREW 5/16-18 X 1-1/4 hex flange head
35259-06	SCREW No. 10-24 X 1/2 hex head (Grade 8)
3536	BOLT 3/8-16 X 1-1/4 hex head (Grade 8)
3560WA	BOLT No. 10-24 X 3/8
3561WC	BOLT No. 10-24 X 3/8
3563	SCREW 1/4-20 X 3/8 hex flange head (Grade 5)
3576	SCREW 5/16-18 X 1/2 hex head, with washer.
3594	SCREW 1/4-20 X 5/8 knurled head (Grade 8)
3601	SCREW 1/4-20 X 1-1/4 knurled head (Grade 8)
3607	BOLT 1/2-13 X 2 hex head (Grade 5)
3612	SCREW No. 10-16 X 1/2 TORX pan head, self-tapping
3622	SCREW No. 10-16 X 3/8 pan head, self-tapping
3656	SCREW No. 8-32 X 3/8 TORX pan head (Grade 5)
36706-01K	BOLT M6 X 1.0 X 30 hex flange head
3676	SCREW 5/16-18 X 5/8 TORX pan head
3684	SCREW 5/16-18 X 1 TORX pan head
3699D	SCREW 3/8-16 X 2.0 hex flange head (Grade 8)
3787	BOLT 1/4-20 X 3/4 hex head (Grade 5)
3892	SCREW 1/4 X 5/8 self-tapping
3901	SCREW 1/4-20 X 1.0 hex flange head (Grade 5)
3929	SCREW 5/16-18 X 1/2 hex head
3976	SCREW 1/4-20 X 1 hex flange head (Grade 5)
3983	SCREW 3/8-16 X 1-5/8 hex flange head, with washer (Grade 8)
4067	BOLT 5/16-18 X 4-1/2 hex head (Grade 5)
4132	SCREW 1/4-20 X 1-1/8 TORX button head (Grade 5) (black)
4194	SCREW No. 10-24 X 5/16 TORX pan head (Grade 5)
4240	SCREW No. 10-24 X 3/16 hex head, with washer
4312C	SCREW M6 X 1.0 X 14mm, SEMS flange head (stainless)
43567-92	SCREW 3/8-16 X 1 TORX pan head, with lockpatch
4365	SCREW 1/4-20 X 1/2 socket button head (Grade 8)
4419	SCREW 5/16-18 X 1-3/4 SEMS hex head
45500118	SCREW M14 X 1.25 X 25 hex socket cap (zinc)
45500132	SCREW M8 X 1.25 X 45 hex socket cap (Grade 8.8)
4597M	SCREW M10 X 1.5 X 30 hex socket head
4612	SCREW 10-24 X 3/4 TORX pan head
46509-01	WASHER 30 X 43 X 2.3
4688	SCREW 3/8-16 X 1-1/4 SEMS hex socket head, with lock patch
4694	SCREW No. 8-32 X 3/8 TORX pan head, with lockpatch
4705	SCREW 1/4-20 X 11/16 SEMS socket head, with lockpatch
4718A	SCREW 1/4-20 X 1-1/2 knurled head, with lockpatch
4740A	SCREW 1/4-20 X 1-1/4 knurled head, with lockpatch (Grade 8)
4741A	SCREW 1/4-20 X 1 socket head, with lockpatch
4775	SCREW 3/8-16 X 1-1/4 hex head (Grade 5)
4790	SCREW No. 10-16 X 3/4 TORX head, self-tapping
4813A	SCREW 1/4-20 X 1-3/8 knurled head, with lockpatch
4816A	SCREW 5/16-18 X 1-1/2 socket head
4820A	SCREW 1/4-20 X 2 socket head
4822A	SCREW 1/4-20 X 2-3/4 knurled head, with lockpatch
4856	SCREW No. 10-24 X 1/2 socket head (stainless)
4924	SCREW 3/8-16 X 7/8 TORX button head (zinc plate) (Grade 5)
57300388	SCREW 3/8-16 X 4.5 hex head (Grade 5)
6019	WASHER 3/8 X 29/32 X 1/16
6036	WASHER 17/64 X 1 X 1/16
6054	WASHER 3/16 X 9/16 X 1/16 nylon (black)
6072	WASHER 3/8 X 1 1/4 X 5/64
6101	WASHER 17/64 X 27/64 X 1/16
6109	WASHER 5/16 X 11/16 X 1/8
6116	WASHER 5/16 X 16/16 X 1/8
6119	WASHER 1/4 X 9/16 X 1/16
6139	WASHER 3/8 X 7/8 X 1/16
6150W	WASHER 3/16 X 3/8 X 1/16
6220W	WASHER 1/4 X 7/16 X 1/32
6237	WASHER 5/16 X 1-1/8 X 5/64
6333	WASHER 5/16 X 7/8 X 5/64
6416	WASHER 3/8 X 1 X 5/64
6497HW	WASHER 29/64 X 1-1/8 X 1/16
6532	WASHER 3/8 X 3/4 X 1/8
6590HW	WASHER 1/2 X 1-1/8 X 3/32
6594	WASHER 5/8 X 1-1/8 X 3/32
6702	WASHER 5/16 X 11/16 X 1/16
6703	WASHER 1/4 X 5/8 X 1/16
67721-48	SCREW 8-32 X 1/4 phillips head self-tapping
6789	WASHER No. 6 X 7/8 X .05
68026-99	SCREW No. 8-32 X 1 Phillips pan head (stainless)
68042-99	SCREW No. 8-32 X 3/8 TORX head
68120-00	SCREW No. 8-32 x 1-2 TORX head, self-tapping
7036	WASHER 1/4 X 31/64 X 1/16
7038	LOCKWASHER 3/8
703B	SCREW 1/4-20 X 7/16 TORX socket button head
7041	LOCKWASHER 5/16
7127	LOCKWASHER 5/16 internal tooth
7130W	LOCKWASHER 3/8 internal tooth
7155	LOCKWASHER 5/16 internal tooth (black)
7330	ACORN NUT 5/16-24 (chrome)
7331	ACORN NUT 5/16-24
7434	WASHER 1/4 X 1-29/64 X 1/16 nylon
7495	NUT M6 X 1.0 flange lock
7499	NUT 1/4-20 large flange
7531	LOCKNUT 5/16-18 X 9/32 X 1/2 flange
7549A	ACORN NUT 5/16-18 X 9/16 X 1/2
7586	JAMNUT 9/32-28 X 1/4
7593	NUT 5/16-24 flange
7600	NUT No. 4-40 keps
7601	LOCKNUT 3/8-16 flange
7606	LOCKNUT No. 8-32 X 1/4 X 1/4 hex (chrome)
7624	LOCKNUT No. 10-24 X 1/4 X 3/8
7629	NUT No. 10-32 X 3/8 keps
7651A	ACORN NUT No. 12-24 (Grade 2) (chrome)
7667	NUT 3/8-16 X 9/32 X 9/16 nylon insert
7686	LOCKNUT 1/4-20 X 5/16 X 7/16
7688	NUT 1/4-20 X 7/32 X 7/16 (Grade 2)
7716	LOCKNUT 1/4-20 X 7/16 flange
7736	ACORN NUT 5/16-24 X 19/32 X 1/2 (Grade 2) (chrome)
7792	NUT 1/4-20 X 1/4 (Grade 2)
780	SCREW 1/4-20 X 7/8 SEMS hex head (Grade 8)
7813A	NUT 5/8-18 X 9/16 X 15/16 (Grade 2)
7825	LOCKNUT 7/16-20 X 7/16 X 5/8
786A	BOLT 5/16-18 X 2-1/4 hex head (Grade 5)
7880	NUT 1/2-13 X 7/16 X 3/4 (Grade 2)
7888A	NUT No. 6-32 flange head
7889	NUT No. 6-32 keps
7900	CLIP NUT 1/4-20
791A	SCREW 3/8-18 X 2-1/4 hex flange head (Grade 5)
7992	ACORN NUT 5/16-18
8020	NUT M24 X 2.0 X 15
8108	SPEEDNUT 1/4-20
84850-92	NUT 3/4-24 X 5/32
856A	SCREW 5/16-24 X 1 socket head (Grade 8)
882	SCREW 1/4-20 X 7/8 knurled head, with washer (Grade 8)
8973	WASHER 1-1/4 X 1-53/64 X 9/64
90770-79	SCREW No. 8-32 X 3/8 Pozidriv head, self-tapping
933	SCREW No. 10-32 X 15/16 Pozidriv truss head (Grade 2)
942	SCREW 1/4-20 X 3/4 TORX button head, with lockpatch (Grade 8)
946	SCREW 1/4-20 X 2-1/4 socket button head, with lockpatch (Grade 8)

Part No.	Description	Part and Model(s)
10080	CLAMP	COOLANT DISTRIBUTION, AIR-COOLED: All Models
10102	CLIP	FRAME AND JIFFY STAND: All Models
1062	SCREW	PRIMARY HOUSING: All Models BRAKE LINES AND MODULE, REAR - ABS: All Models FAIRING, INNER - FLTRXP (1 OF 2): FLTRXP
11000101	OIL SEAL	SHIFTER, GEAR: All Models TRANSMISSION BEARINGS AND COVERS: All Models
11105	O-RING	TRANSMISSION HOUSING, COVER AND OIL PAN: All Models PRIMARY HOUSING: All Models
11132A	O-RING	ROCKER ARM ASSEMBLY AND PUSHRODS: All Models TRANSMISSION BEARINGS AND COVERS: All Models
11145A	O-RING	ROCKER ARM ASSEMBLY AND PUSHRODS: All Models
11150	RETAINING RING	SHIFTER, GEAR: All Models
11293	O-RING	ROCKER ARM ASSEMBLY AND PUSHRODS: All Models CAMSHAFTS AND CAMSHAFT COVER: All Models
11900103	O-RING	CAMSHAFTS AND CAMSHAFT COVER: All Models
12052A	SEAL	PRIMARY HOUSING: All Models
17369-06	GASKET SERVICE KIT	PRIMARY HOUSING: All Models
2445	SCREW	WINDSHIELD, FAIRING AND HEADLAMP - FLHTP: FLHTP FAIRING, INNER - FLHTP (1 OF 2): FLHTP
2446	SCREW	LICENSE PLATE BRACKETS: FLHTP
2531	SCREW	FENDERS, FRONT: All Models
2563	SCREW	INSTRUMENTS - FLHTP: FLHTP INSTRUMENTS - FLTRXP: FLTRXP WINDSHIELD, FAIRING AND HEADLAMP - FLTRXP (1 OF 2): FLTRXP FAIRING, INNER - FLHTP (1 OF 2): FLHTP FAIRING, INNER - FLTRXP (1 OF 2): FLTRXP
25700378	GASKET	PRIMARY HOUSING: All Models
25700455	GASKET	PRIMARY HOUSING: All Models
25700731	GASKET KIT	ROCKER ARM ASSEMBLY AND PUSHRODS: All Models CAMSHAFTS AND CAMSHAFT COVER: All Models
25700746	GASKET KIT	PRIMARY HOUSING: All Models
27300087	SEAL	INDUCTION MODULE, FUEL: All Models
27444-00Y	O-RING	STARTER MOTOR: All Models
3050	SCREW	ALTERNATOR AND REGULATOR: All Models
3275	SCREW	INDUCTION MODULE, FUEL: All Models SENSORS AND SWITCHES, ENGINE: All Models
34091-08	BEARING	TRANSMISSION GEARS: All Models
35654-06	GASKET	TRANSMISSION BEARINGS AND COVERS: All Models
3656	SCREW	SADDLEBAGS: All Models
36805-06	GASKET	TRANSMISSION BEARINGS AND COVERS: All Models
4132	SCREW	CLUTCH CONTROL: All Models BRAKE CONTROL, FRONT: All Models
41751-06A	GASKET	BRAKE CONTROL, FRONT: All Models BRAKE LINES, FRONT - ABS: All Models BRAKE LINES AND MODULE, REAR - ABS: All Models
43567-92	SCREW	WHEELS, REAR: All Models
4740A	SCREW	CAMSHAFTS AND CAMSHAFT COVER: All Models
5210	WELL NUT	NACELLE AND HEADLAMP - FLHP (1 OF2): FLHP
6054	WASHER	WINDSHIELD, FAIRING AND HEADLAMP - FLTRXP (1 OF 2): FLTRXP LOOSE PARTS: FLTRXP
60678-85	RETAINING RING	PRIMARY HOUSING: All Models
65324-83B	GASKET	EXHAUST SYSTEM - (1 OF 2): All Models
65325-83A	RETAINING RING	EXHAUST SYSTEM - (1 OF 2): All Models
6702	WASHER	SHIFTER, GEAR: All Models SEAT: All Models SIREN AND AMPLIFIER: All Models
7041	LOCKWASHER	EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHTP: FLHTP EXHAUST SYSTEM - (1 OF 2): All Models
7586	JAMNUT	SADDLEBAGS: All Models
7593	NUT	EXHAUST SYSTEM - (1 OF 2): All Models
7600	NUT	FENDERS, FRONT: All Models
7716	LOCKNUT	FOOTBOARDS: All Models
786A	BOLT	PRIMARY HOUSING: All Models
856A	SCREW	SHIFTER, GEAR: All Models
933	SCREW	WINDSHIELD, FAIRING AND HEADLAMP - FLTRXP (1 OF 2): FLTRXP LOOSE PARTS: FLTRXP
9955	CLAMP	EXHAUST SYSTEM - (1 OF 2): All Models

Part No.	Description	Part and Model(s)
41852-08B	PAD AND PIN KIT	BRAKE CALIPER, REAR: All Models
41854-08	PAD AND PIN KIT	BRAKE CALIPER, FRONT: All Models
46514-01A	OIL SEAL	FORKS, FRONT: All Models
46615-06	PACKING SEAL	FORKS, FRONT: All Models

Part No.	Description	Part and Model(s)
49725-07A	SPRING	FRAME AND JIFFY STAND: All Models
50245-07	BUMPER	FRAME AND JIFFY STAND: All Models

Part No.	Description	Part and Model(s)
70345-84	RETAINER	HANDLEBAR: FLHP
72023-51E	SWITCH KIT	BRAKE LINES AND MODULE, REAR - ABS: All Models SWITCHES: All Models
72330-95	FUSE	WIRING HARNESS, MAIN, ABS - FLHTP (8 OF 9): FLHTP WIRING HARNESS, MAIN, ABS - FLHP (8 OF 9): FLHP WIRING HARNESS, MAIN, ABS - FLTRXP (8 OF 9): FLTRXP

Part No.	Description	Part and Model(s)
18538-99C	HYDRAULIC LIFTER	ROCKER ARM ASSEMBLY AND PUSHRODS: All Models
29400183	BREATHER ASSEMBLY	ROCKER ARM ASSEMBLY AND PUSHRODS: All Models
29400210	BREATHER ASSEMBLY	ROCKER ARM ASSEMBLY AND PUSHRODS: All Models
33600091	SHAFT	SHIFTER, GEAR: All Models
37909-90	RING	CLUTCH: All Models

Part No.	Description	Part and Model(s)
61011-04A	FUEL FILTER KIT	FUEL PUMP - FLHTP, FLTRXP : FLHTP FLTRXP FUEL PUMP - FLHP: FLHP
65900015	CLAMP	EXHAUST SYSTEM - (2 OF 2): All Models

Index No.	Part No.	Description	Model(s)
1	16589-99B	DOWEL PIN (4)	ALL
2	10200303	FLANGE NUT (dull silver) (8)	ALL
3	10900015A	STUD, exhaust port (4)	ALL
4	16500305	GASKET, cylinder head (4.016 in) (2)	ALL
5	16500332	GASKET, cylinder base (2)	ALL
6	16500388	CYLINDER HEAD, rear, with 3, 9, 10, 11, 12, 13, 14, 15 & 65324-83B (Air-Cooled) (black)	ALL
6	16500393	CYLINDER HEAD, front, with 3, 9, 10, 11, 12, 13, 14, 15 & 65324-83B (Air-Cooled) (black)	ALL
7	16800063	STUD, cylinder (8)	ALL
8	16800075	CYLINDER, front, with 16589-99B (4.016 in) (black)	ALL
8	16800080	CYLINDER, rear, with 16589-99B (4.016 in) (black)	ALL
9	18000016	INTAKE VALVE (4)	ALL
10	18000034A	EXHAUST VALVE (4)	ALL
11	18100140	VALVE SPRING (8)	ALL
12	18100044	SEAL, valve (8)	ALL
13	18100045	COLLAR, valve spring (8)	ALL
14	18100060	KEEPER, valve (16)	ALL
15	18400073B	SOLENOID, auto compression release (ACR) (2)	ALL
16	25700729	GASKET KIT, top end	ALL
16	25700730	GASKET KIT, engine overhaul	ALL

Index No.	Part No.	Description	Model(s)
1	3976	SCREW (2)	ALL
2	4741A	SCREW (8)	ALL
3	11132A	O-RING, pushrod cover (4)	ALL
4	11145A	O-RING, pushrod cover (4)	ALL
5	11293	O-RING (4)	ALL
6	17945-36B	CAP, cover spring (4)	ALL
7	17947-36	SPRING, pushrod cover (4)	ALL
8	17948-99A	COVER, pushrod (upper) (4)	ALL
9	17968-99	RETAINER, spring cap (4)	ALL
10	18538-99C	HYDRAULIC LIFTER (4)	ALL
11	10200258	SCREW (2)	ALL
12	10200308	SCREW (20)	ALL
13	10200446	SCREW (8)	ALL
14	10200503	SCREW (8)	ALL
15	10500069	SPACER, rocker cover (2)	ALL
16	11900116	O-RING (2)	ALL
17	17300053	ROCKER ARM, rear intake, front exhaust (2)	ALL
18	17300055	ROCKER ARM, front intake, rear exhaust (2)	ALL
19	17300059B	SHAFT, rocker arm (4)	ALL
20	17900030	PUSHROD, intake, 10.301 in long (light blue stripes) (2)	ALL
21	17900031	PUSHROD, exhaust, 10.531 in long (yellow stripes) (2)	ALL
22	17900034	ANTI-ROTATION DEVICE, rear cylinder	ALL
22	17900035	ANTI-ROTATION DEVICE, front cylinder	ALL
23	25700362A	GASKET, lifter cover (2)	ALL
24	25700372B	GASKET, rocker arm cover (2)	ALL
25	25700409	ROCKER COVER, upper (chrome) (2)	ALL
26	25700410	LIFTER COVER, front (chrome)	ALL
26	25700411	LIFTER COVER, rear (chrome)	ALL
27	25700425A	GASKET, rocker housing, lower (2)	ALL
28	25701000	COVER, pushrod (lower) (4)	ALL
29	25701495	ROCKER COVER ASSEMBLY, lower, with 25700425A (chrome) (2)	ALL
30	25700731	GASKET KIT, camshaft service	ALL
31	29400183	BREATHER ASSEMBLY, rear, with 11900116	ALL
31	29400210	BREATHER ASSEMBLY, front, with 11900116	ALL

Index No.	Part No.	Description	Model(s)
1	4705	SCREW	ALL
2	10200446	SCREW (4)	ALL
3	10800052	CLAMP (3)	ALL
4	11900090	O-RING, coolant manifold (4)	ALL
5	11900092	O-RING, transmission oil return	ALL
6	26900117	BRACKET, coolant tube (2)	ALL
7	62700146	FITTING ASSEMBLY, transmission oil return, with 11900092	ALL
8	62800028	COOLANT LINE ASSEMBLY, oil, with 3, 4, 6, 9, 10, 11, 12	ALL
9	26900144	HOSE	ALL
10	62700161	HOSE	ALL
11	10800109	CLAMP	ALL
12	10800111	SLEEVE	ALL

Index No.	Part No.	Description	Model(s)
1	882	SCREW (2)	ALL
2	10080	CLAMP (zinc) (2)	ALL
3	69201286A	COVER, electrical connector, with 12600016	ALL
4	10344	CLAMP (black) (2)	ALL
5	11692	GROMMET (2)	ALL
6	70681-09	RETAINER, wire harness	ALL
7	72213-94	TERMINAL, socket, 16-20 AWG (2)	ALL
8	72606-08	HOUSING, two-way socket (black)	ALL
9	72609-08	SECONDARY LOCK, two-way socket	ALL
10	72610-08	WIRE SEAL, 18-20 AWG (white) (2)	ALL
11	10200414	SCREW (2)	ALL
12	10200422	SCREW (2)	ALL
13	10800052	CLAMP	ALL
14	12600016	CLIP, push-in (2)	ALL
15	12700090	BRACKET, voltage regulator	ALL
16	26800092	COVER, oil cooler	ALL
17	26800095	COOLING FAN, with 72213-94, 72606-08, 72609-08 and 72610-08	ALL
18	62700133	OIL COOLER	ALL
19	62700143	HOSE, inlet, oil cooler	ALL
20	62700144	HOSE, outlet, oil cooler	ALL

Part No.	Description	Part and Model(s)
68000056	BULB	EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHP: FLHP EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHTP: FLHTP
68168-89A	BULB	EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHP: FLHP EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHTP: FLHTP WINDSHIELD, FAIRING AND HEADLAMP - FLTRXP (1 OF 2): FLTRXP
68572-64B	BULB	TURN SIGNALS, REAR: All Models
68973-00	LENS	EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHTP: FLHTP WINDSHIELD, FAIRING AND HEADLAMP - FLTRXP (1 OF 2): FLTRXP TURN SIGNALS, REAR: FLHTP FLTRXP

Part No.	Description	Part and Model(s)
43109-09A	TIRE	WHEELS, FRONT: All Models
43200027	TIRE	WHEELS, REAR: All Models

ENGINE ASSEMBLY - Milwaukee-Eight® 114 engine

CYLINDERS, HEADS AND VALVES

ROCKER ARM ASSEMBLY AND PUSHRODS

COOLING SYSTEM, ENGINE, AIR-COOLED

COOLANT DISTRIBUTION, AIR-COOLED

PISTONS AND FLYWHEEL ASSEMBLY - Milwaukee-Eight® 114 engine

CRANKCASE

CAMSHAFTS AND CAMSHAFT COVER

ENGINE MOUNTS AND STABILIZER LINK

INDUCTION MODULE, FUEL

AIR CLEANER

ALTERNATOR AND REGULATOR

ELECTRONIC CONTROL MODULE (ECM) AND COIL

SENSORS AND SWITCHES, ENGINE

STARTER MOTOR

SHIFTER, GEAR

TRANSMISSION BEARINGS AND COVERS

TRANSMISSION HOUSING, COVER AND OIL PAN

TRANSMISSION GEARS

CLUTCH

PRIMARY HOUSING

BELT, CHAIN AND SPROCKETS

CLUTCH CONTROL

BRAKE CONTROL, FRONT

MIRRORS

BRAKE LINES, FRONT - ABS

BRAKE CONTROL, REAR

BRAKE LINES AND MODULE, REAR - ABS

BRAKE CALIPER, FRONT

BRAKE CALIPER, REAR

WHEELS, FRONT

WHEELS, REAR

FORK BRACKETS, FRONT

FORKS, FRONT

SHOCK ABSORBERS, REAR

FRAME AND JIFFY STAND

COVERS AND AIR DEFLECTORS

FRAME AND FORK, REAR AND TOUR-PAK SUPPORT

SEAT

FOOTBOARDS

FENDERS, FRONT

FENDERS, REAR

LICENSE PLATE BRACKETS

FUEL TANK - FLHTP, FLTRXP

FUEL TANK - FLHP

CONSOLE, FUEL TANK - FLHTP, FLTRXP

INSTRUMENTS, FUEL TANK - FLHP

INSTRUMENTS - FLHTP

INSTRUMENTS - FLTRXP

INSTRUMENT- FLHP

INSTRUMENT HOUSING - FLTRXP

FUEL PUMP - FLHTP, FLTRXP

FUEL PUMP - FLHP

EVAPORATIVE EMISSIONS COMPONENTS

NACELLE AND HEADLAMP - FLHP (1 OF2)

NACELLE AND HEADLAMP - FLHP (2 OF 2)

EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHP

EMERGENCY LAMPS AND TURN SIGNALS, FRONT - FLHTP

WINDSHIELD - FLHP

WINDSHIELD, FAIRING AND HEADLAMP - FLHTP

WINDSHIELD, FAIRING AND HEADLAMP - FLTRXP (1 OF 2)

WINDSHIELD, FAIRING AND HEADLAMP - FLTRXP (2 OF 2)

FAIRING, INNER - FLHTP (1 OF 2)

FAIRING, INNER - FLHTP (2 OF 2)

FAIRING, INNER - FLTRXP (1 OF 2)

FAIRING, INNER - FLTRXP (2 OF 2)

SWITCHES, HANDLEBAR, LEFT

SWITCHES, HANDLEBAR, RIGHT

HANDLEBAR

THROTTLE CONTROL

TAIL LAMP

TURN SIGNALS, REAR

MARKER LIGHT, REAR

EXHAUST SYSTEM - (1 OF 2)

EXHAUST SYSTEM - (2 OF 2)

WIRING HARNESS, MAIN, ABS - FLHTP (1 OF 9)

WIRING HARNESS, MAIN, ABS - FLHTP (2 OF 9)

WIRING HARNESS, MAIN, ABS - FLHTP (3 OF 9)

WIRING HARNESS, MAIN, ABS - FLHTP (4 OF 9)

WIRING HARNESS, MAIN, ABS - FLHTP (5 OF 9)
